Specification:
Dimension: 11500mm*2500mm*3700mm
Tare Weight: about 8000kg
Total Volume: 42000L or customized
Main Beams: Q345B carbon steel
Tank Body Material: 5mm Q235 carbon steel
End plate: 6mm Q235 carbon steel
Manhole Cover: carbon steel
Bottom Valve: aluminum API pneumatic bottom valve
Discharging Valve: diameter is 4 inch
Compartments: 3 compartments or customized
Discharging Pipe: 4 inch rubber hose, 2pcs, 6m/each
Axle: 3 axles*13T/14T/16T*BPW/ FUWA brand
Landing Gear: JOST brand
King Pin: JOST 2.0 or 3.5 inch
Suspension: mechanical suspension
Leaf Spring: 90(w)mmx13(thickness)x10 layers
Braking System: WABCO brand
Rim: 9.00-22.5/8.00-20
Tire: 12 units, 12.00R22.5/315.80R22.5/11.00R20/12.00R20
ABS: optional
Painting: 1 layer of anticorrosive primer and 2 layer of top coats
Accessories: one standard tool box
Shipping Terms: by bulk cargo/RORO/container
Color: optional
Advantage:
A: The 3 axle 42000l tank semi trailer made of high-strength wear-resistant steel plate of yuhang vehicle can be applied to a variety of different and complex road conditions to meet the needs of customers for loading and transportation.
B: The tank body is integrally formed by robotic automatic welding technology, which ensures high-quality welds, long service life, low maintenance cost and beautiful appearance.
C: All tank semi trailer have to go through pressure test and metal inspection test before leaving the factory to ensure that the tank body has good sealing performance.
D: Shot blasting treatment of the whole vehicle to remove rust and oil stains, improve paint adhesion, one-time primer, uniform paint film thickness, and corrosion resistance.
